Output

• Output power capacity: 12.0 KWatts / 15.0 kVA
• Max Configurable Power (Watts): 12.0 KWatts / 15.0 kVA
• Nominal Output Voltage: 400V 3PH
• Output Voltage Note: Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage
• Efficiency at Full Load: 95.7 %
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 – 53 Hz for 50 Hz nominal
• Output Frequency (not synced): 50Hz +/- 0.1% for 50Hz nominal
• Other Output Voltages: 380, 415
• Load Crest Factor: 3 : 1
• Topology: Double Conversion Online
• Waveform type: Sine wave
• Maximum Output Current: 24
• Bypass: Built-in Maintenance Bypass, Built-in Static Bypass

Input

• Nominal Input Voltage: 400V 3PH
• Input frequency: 40 – 70 Hz (auto sensing)
• Input Connections: Hard Wire 5-wire (3PH + N + G)
• Input voltage range for main operations: 304 – 477V
• Efficiency at Full Load: 95.7 %
• Other Input Voltages: 380, 415
• Maximum Input Current: 21.0A
• Input Power Factor at Full Load: 0.98

Batteries & Runtime

• Battery type: VRLA
• Included Battery Modules: 2
• Typical recharge time: 5hour(s)
• Nominal Battery Voltage: +/-192 V (split battery referenced to neutral)
• Expected Battery Life (years): 3 – 5
• RBC Quantity: 2
• Extendable Run Time: 1
• Extended Run Options: APC-Smart-UPS-VT-15kVA-400V-w-2-Batt-Mod-Start-Up-5X8-Int-Maint-Bypass-Parallel-Capable
• End of Discharge Battery Voltage: +/-154 V
• Runtime: View Runtime Graph/View Runtime Chart

Communications & Management

• Interface Port(s): DB-9 RS-232 , Smart-Slot
• Pre-Installed SmartSlot™ Cards: AP9631
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Audible and visible alarms prioritized by severity
• Emergency Power Off (EPO): Yes

Physical

• Maximum Height: 1490mm , 149.0CM
• Maximum Width: 352mm , 35.2CM
• Maximum Depth: 842mm , 84.2CM
• Net Weight: 396.82KG
• Shipping weight: 428.18KG
• Shipping Height: 1643mm , 164.3CM
• Shipping Width: 650mm , 65.0CM
• Shipping Depth: 1062mm , 106.2CM
• Color: Black
• Units per Pallet: 1.0

Environmental

• Operating Temperature: 0 – 40 °C
• Operating Relative Humidity: 0 – 95 %
• Operating Elevation: 0-999.9meters
• Storage Temperature: -50 – 40 °C
• Storage Relative Humidity: 0 – 95 %
• Storage Elevation: 0-15000meters
• Audible noise at 1 meter from surface of unit: 64.0dBA
• Online thermal dissipation: 2170.0BTU/hr
• Protection Class: IP 20

Conformance

• Approvals: C-tick, CE, EN 50091-2, EN/IEC 62040-3, IEC 61000-3-2, IEC 61000-3-3, ISO 14001, ISO 9001, RCM, VFI-SS-111
• Standard warranty: 1 year repair or replace, Start-Up Service
